Low energy photons are absorbed more readily due to lower penetration ability [5]; therefore, removing them prior to x-ray exposure has the potential to reduce the patient dose without considerably decreasing the image quality, which would benefit the field of mammography by delivering a more effective balance between …

What is the reason of filtering low energetic X-rays?

For medical purposes, X-ray filters are used to selectively attenuate, or block out, low-energy rays during x-ray imaging (radiography). Low energy x-rays (less than 30 keV) contribute little to the resultant image as they are heavily absorbed by the patient’s soft tissues (particularly the skin).

How are low energy X-rays removed from the beam?

Filters are metal sheets placed in the x-ray beam between the window and the patient that are used to attenuate the low-energy (soft) x-ray photons from the spectrum.

What is the advantage of using a filter that blocks the low energy X-rays?

Filtration reduces x-ray intensity, but not the maximum energy of the x-ray beam spectrum. The change in the shape of the beam spectrum with filtration is referred to as beam hardening. This is due to the loss of lower energy photons from a polychromatic beam.

What is a use of low energy X-rays?

The low energy X-ray calibration service is intended for thin-window plane-parallel chambers required for the dosimetry of superficial X-ray beams (typically less than 70 kVp). Farmer-type chambers can also be calibrated.

What material absorbs xray?

Calcium in bones absorbs x-rays the most, so bones look white. Fat and other soft tissues absorb less and look gray. Air absorbs the least, so lungs look black.

What is the advantage of wedge filter?

It eliminates the randomness sometimes found in cheaper screens and allows for precise quality control. A wedge wire filter is said to be a brewer’s best friend, and many other industries rely on stainless steel wedge wire screen to be sure that there will be no contaminants in their products.

What kind of filter is used for radiation therapy?

The simplest form of intensity modulation, wedge filters, has been in use in radiotherapy since the 1960s. A wedge is an angled piece of high-density material that preferentially attenuates a photon beam on its thick end, resulting in a dose gradient across the beam.

Why are wedges used in radiation therapy?

In radiation therapy, wedge filters are commonly used to improve dose uniformity toward the target volume [2]. A physical wedge is usually constructed from a high-density material, such as lead or steel, which attenuates the beam progressively across the entire field.

What are wedges and compensators radiotherapy?

In radiation oncology, wedge filters are commonly used to improve the dose uniformity in the target volume. They can be used as missing tissue compensators or wedge pairs to alter the shape of isodose curves so that two beams can be angled with a small hinge angle at a target volume without creating a hotspot.

Article first time published on

Why do we use filters in radiotherapy?

Purpose: The flattening filter (FF) has traditionally been used to flatten beams or create uniform fields in conformal and intensity-modulated radiation therapy (IMRT) but reduces the dose rate.

What is MLC in radiotherapy?

Segmental MLC (SMLC) uses a set of fixed MLC segment shapes to deliver the intensity pattern with the beam off as the MLC moves from one shape to the next. From: Clinical Radiation Oncology (Fourth Edition), 2016.

What is virtual wedge in radiotherapy?

Virtual Wedge (VW) is a Siemens treatment modality which generates wedge-shaped dose distributions by moving a collimator jaw from closed to open at a constant speed while varying the dose rate in every 2 mm jaw position.

What is breast cone in radiotherapy?

The Tangential Breast Cone for the Best Theratronics Theratron machines is a device designed to eliminate penumbra and beam divergence for the breast tangential portals. The device consists of a support plate and lead block for shielding of the contralateral side.

What is flattening filter in Linac?

It is well known that the flattening filter in a standard linac acts as an attenuator, the beam hardener and the scatterer. Obviously, the removal of the FF results in an increase in dose rate, softening of the x-ray spectra, reduction in head scattered radiation, and the nonuniform beam profile.

What is wedge factor?

Wedge factor at a depth (d) in water for a field size (FS), and at a certain SSD was defined as the ratio of the dose with the wedge beam, Dw (FS, d), to the dose with open beam, Do(FS, d).

What is dynamic wedge?

Modern medical accelerators are usually equipped with a dynamic wedge option. It is a form of dose-rate modulation which makes use of the dynamic movement pairs of collimator jaws. Dynamic wedges may replace physical wedges but their use requires more complex dosimetry and quality control procedures.

What is wedge filter?

Wedge filter means a filter which effects continuous change in transmission over all or a part of the useful beam.

When was tomotherapy invented?

History. The tomotherapy technique was developed in the early 1990s at the University of Wisconsin–Madison by Professor Thomas Rockwell Mackie and Paul Reckwerdt.

What is the use of proton?

Proton therapy, also called proton beam therapy, is a type of radiation therapy. It uses protons rather than x-rays to treat cancer. A proton is a positively charged particle. At high energy, protons can destroy cancer cells.

What is beam modification?

Beam modifying devices are devices which when kept in path of beam produces a desirable modification in the special distribution of the beam. Types of beam modification are as follows: Shielding: To eliminate radiation dose to selected part of the treatment area.

How effective is stereotactic radiation therapy?

Early results suggest that SBRT is as effective as, and likely more effective than standard radiation therapy – especially for early stage lung cancer, gastrointestinal tumors such as pancreatic tumors, and liver tumors.

What is the difference between IMRT and VMAT?

VMAT is a type of IMRT technique. VMAT stands for Volumetric Arc Therapy. VMAT can also be called Rapid Arc. VMAT is different to normal IMRT in that the radiotherapy machine rotates around the patient during a radiotherapy beam in an arc shape.

What is the tongue and groove effect?

The tongue and groove effect is an underdosing effect which can occur in certain applications of multileaf collimators. It results from the need to overlap adjacent leaves of a multileaf collimator in order to limit leakage between leaves.

What is an isodose curve?

An isodose curve (or contour) is a line of constant absorbed dose. The line is in a plane and, for single radi- ation beams, its value is usually related by a simple percentage value (e.g., 90 percent, 80 percent, etc.) to the peak absorbed dose (or the surface absorbed dose, for x rays below 400 kV) on the beam axis.

How do you measure a wedge angle?

When light passes through an optical wedge, the beam is deflected by some angle, δ, which is defined by the refractive index of the glass, n, and the glass’s mechanical wedge angle, α. The calculation for this is given by the formula: δ = 2(n-1) · α.

Does radiation change the shape of your breast?

In time radiotherapy can cause the breast tissue to change shape or shrink in size a little. This can happen to your natural breast tissue or a reconstructed breast. After radiotherapy, the breast might feel hard and less stretchy. This is due to a side effect called radiation fibrosis.
