Only One Speed From Blower Motor. One of the most common symptoms of trouble with the blower motor resistor is when the fan gets stuck in one setting. … Various Airflow Settings Not Working. … No Air Coming From Vents.

How do I know if my blower motor resistor is bad?

1. Only One Speed From Blower Motor. One of the most common symptoms of trouble with the blower motor resistor is when the fan gets stuck in one setting. …
2. Various Airflow Settings Not Working. …
3. No Air Coming From Vents.

How long does it take to replace a blower motor resistor?

takes about 45 minutes.

How do you change a blower motor speed resistor?

1. Remove the negative battery terminal. …
2. Locate the blower motor resistor on the passenger side under the dash board. …
3. Disconnect the electrical connector to the blower motor resistor.
4. Remove the screws or bolts to the blower motor resistor and remove the resistor.
5. Installation is the reverse of the removal.

What happens when blower motor resistor goes bad?

Problems with a blower motor resistor are common in many cars. The most common symptom of a failed blower motor resistor is when the heater fan only runs at the highest speed setting (4 or 5) and doesn’t work at low speeds. In some cars, a failed blower motor resistor can cause a heater fan to stop working completely.

How do you fix a blower motor resistor?

1. Step 1: Remove the glove box door, if necessary. …
2. Step 2: Disconnect the wiring harness and remove screws. …
3. Step 3: Remove and replace the blower motor resistor. …
4. Step 4: Tighten screws and reattach wiring harness. …
5. Step 5: Reinstall the glove box door.

What happens when blower resistor goes bad?

If the resistor shorts or fails, it may cause the blower motor to remain stuck on one fan speed. The heating and air conditioning systems may still function at one speed, however the resistor will have to be replaced in order for full functionality to be restored.

Can a blower motor resistor be bypassed?

Blower resistors are made of several resistors with different resistances. … In the highest speed state, the blower resistor is bypassed completely and the fan is connected directly to the car’s battery, which allows maximum current through the motor.

How do you replace a resistor?

Take the circuit board on which the resistor is soldered and cut the wire leads with diagonal cutters. Remove the defective resistor. Turn on the soldering iron. Place the tip on the lead and the pad through which the lead is placed until the solder melts.

Why does my blower motor resistor keep burning out?

Trent, one of the biggest reasons for blower motor resistors to have shorten life is actually because of faulty blower motor drawing too many amps, some times melting wires/plugs, heating up resistors shortening their life.

Article first time published on

Why does my air only work on high?

When a blower resistor fails, the highest fan speed usually is the only one that still works because it essentially bypasses the resistor and receives the maximum amount of voltage. When the resistor is working, it reduces the amount of voltage going to the lower fan speeds, so the fan runs slower.

Is it the resistor or the blower motor?

The blower motor resistor is an electrical component that is a part of the vehicle’s heating and air conditioning system. It is responsible for controlling the blower motor’s fan speed.

Is there a fuse for the blower motor?

Many vehicles have two fuses for the blower motor, one in the interior fuse block and the other under the hood. The blower motor is usually under the dashboard on the passenger side.

Why does my blower motor fuse keep blowing?

Blown fuses If the blower motor relay develops any sort of problem that hinders its ability to properly limit and distribute power, it may cause the blower motor fuse to blow. Any sort of electrical spikes or excessive current from a bad relay will blow the fuse and cut power in order to protect the system.

How do you know if a resistor is bad?

A good resistor should test within its rated range. A bad resistor will either show infinite resistance or a measurement far higher than its rated resistance. In either case the resistor is no longer functioning properly.

What happens if a resistor burns out?

When a resistor breaks down, current typically flows through the burnt resistor without any resistance and thereby passes unchecked. Other components in the circuit may become damaged from the excess current flowing through.

Why does my blower motor work sometimes?

When a resistor fails, the fan will often run only at higher speeds or the highest speed, no matter what fan speed is selected. … When a blower resistor fails, the highest fan speed usually is the only one that still works because it essentially bypasses the resistor and receives the maximum amount of voltage.

What are the symptoms of a bad blower motor?

• Poor or Airflow from Air Vents. This will be the first and most obvious sign your blower motor has a problem. …
• No Airflow At All From Vents. …
• Skyrocketing Energy Bills. …
• Strange Noises When You Turn on the Heat. …
• Overheating Blower / Weird Smells.

How much does it cost to fix AC in Impala?

On average, the cost for a Chevrolet Impala Car AC Repair is $245 with $112 for parts and $133 for labor. Prices may vary depending on your location.

Where is the blower motor fuse on a 2011 Chevy Impala?

The blower motor fuse on a 2011 chevy impala is located in the main fuse panel that is located under the hood of the vehicle.

Where is the blower motor resistor on a 2012 Chevy Impala?

The blower motor resistor on the 2012 Chevy impala is inside the dash on the opposite side of the steering wheel.

Where is the blower motor relay on a 2004 Chevy Impala?

The 2004 Chevy Impala blower motor relay location is to the left of the steering wheel.To get to the fuse box look to the left of the steering wheel look for a small seam or crack along the dash. Using a screwdriver or prybar You will want to pop this open. On the inside, You will find a bunch of fuses.

Why does my blower motor not work?

In a situation where the motor doesn’t work on any speed, the most likely causes are: a blown power supply fuse, a bad motor ground connection, bad motor speed control module or a failed motor. On all systems, a failed blower motor is least likely. … Start by checking the blower fuse and HVAC controller fuse.

Where is the blower motor relay located?

The blower motor relay is generally located in the under-hood fuse box or in the under-dash fuse box. A blown fuse can mimic relay failure.

Can you put a resistor in the wrong way?

A resistor is a small component that’s designed to provide a specific amount of resistance in an electronic circuit. … Resistors are blind to the polarity in a circuit. Thus, you don’t have to worry about installing them backwards. Current can pass equally through a resistor in either direction.

Can you test a blower motor resistor with a test light?

Unplug the blower motor and test for power using the 12-volt test light in the same manner as explained in Step 1. … If there is power indicated on high blower speed, but not low or mid range, the problem is the blower resistor.

Can you bypass a resistor?

All current will bypass the resistor and travel through the short. The voltage across the 100Ω resistor is going to be zero. The 100Ω resistor is not impacting the circuit.

What is blower motor relay?

In a blower motor, the relay supplies the power that allows the fans to circulate warmed air. Essentially an on/off switch, the blower motor relay’s reactions start and end the heating process in HVAC systems by controlling the flow of current between the power source and the motor.
