Monoflow tees are used to divert some water from the main loop into each radiator. Use one monoflow tee on the return if the radiator(s) are located above the main loop; use two monoflow tees if the radiators are installed below the main loop.

What is a diverter tee?

Diverter tee systems are an upgrade from basic series piping circuits. They allow each heat emitter served by a single piping loop to be independently controlled. … Diverter tees can also be used to supply a piping subassembly such as the one shown in Figure 3.

How does a venturi tee work?

Venturi Principle|How do venturis work. A venturi creates a constriction within a pipe (classically an hourglass shape) that varies the flow characteristics of a fluid (either liquid or gas) travelling through the tube. As the fluid velocity in the throat is increased there is a consequential drop in pressure.

How does a Monoflo system work?

Fourth tee (a Monoflo) comes from the down-feed radiator. In other words, you alternate the up and down connections. That produces more resistance to flow along the main and nudges more hot water into the radiators.

What is a flow tee?

A Flow Tee is a special fitting that is mainly used in pipeline pigs past tee connections – where flow bypass often leaving pigs stranded without restricting product flow. The Flow tees can be barred or sphere.

How does a centrifugal circulating pump create flow in the hydronic system?

Force the hot water from the heat source through the piping to the heat transfer units and back to the boiler. These pumps use centrifugal force to circulate the water through the system. The rotating part of a pump that causes the centrifugal force to develop fluid flow and pressure difference.

What is the advantage to a two pipe system direct return?

Advantages. The advantage with the two-pipe reverse return system is that the pipe run to each radiator is about the same, this ensures that the frictional resistance to the flow of water in each radiator is the same. This allows easy balancing of the system.

Why does pressure drop in a venturi?

The pressure increases over the smaller surface area, while the narrow flow then creates a vacuum in the water. The fluid’s kinetic energy increases results in a pressure decrease.

What type of valve can be used for mixing water in a hydronic system?

For most hydronic applications, thermostatic valves are typically three-way valves used for small- to medium-sized projects. Plumbing code changes adopted in most jurisdictions across Canada now require the control of hot water temperature through the use of thermostatic mixing valves.

What is the purpose of a Venturi?

A Venturi is a system for speeding the flow of the fluid, by constricting it in a cone shape tube. In the restriction the fluid must increase its velocity reducing its pressure and producing a partial vacuum. As the fluid leave the constriction, its pressure increase back to the ambient or pipe level.

Article first time published on

How do you increase venturi suction?

You can increase air/steam flow to the diffuser or increase the pressure differential from the motive force to the suction stream. I.E. make the diffuser longer and narrower ( larger pipe to a smaller pipe to incresase the pressure into the suction chamber to create greater vacuum).

What is a split tee fitting?

It is a pipeline fitting designed such that the inner diameter of the fitting is the same size as the outside diameter of the pipe that will be hot tapped. As a rule of thumb, a split tee is used when the branch connection is equal to or greater than half the diameter of the run direction.

What is the disadvantage of two pipe direct return system?

A direct return system requires less main piping, but because flow will be uneven (favoring the front terminals), the system will require manual or automatic balancing valves. Disadvantage: Uneven flow. It causes less cooling for the farthest load point.

What are the disadvantages of two pipe system?

The two-pipe system’s main limitation is its lack of operating flexibility. Depending on the facility’s needs, the system’s hydronic piping circuit that runs throughout the building must connect to the boiler or the chiller.

Which is better one pipe or two pipe system?

The two pipe system is much more efficient than the single pipe system but still needs to be balanced properly at the end of the installation.

What are circulating pumps used for?

Circulating Pumps A circulation pump (also known as a recirculation pump) circulates fluid in a closed circuit with the intent of ensuring hot water is always available close to the consumption point. Consequently, water circulation pumps are commonly used to circulate the water in hydronic heating or cooling systems.

What is the point of no pressure change?

Essentially, the PONMIPC is that place in the system to which the expansion tank is connected. Regardless of the pump’s location in relationship to this point, it cannot cause any mechanically induced pressure changes at this point.

How do circulating pumps work?

By adding a circulator pump, water is circulated through the cool pipes from the heater to the farthest fixture. The cool water is circulated back to the heater via the cold-water line, and no water is wasted during the wait. The energy use of the circulation pump is less than operating a 25-watt light bulb.

Can you pump into a mixing valve?

Best practice is to pump away from the mixing valve, not into it. … If there is no cold inlet flow, the thermostatic element will see only hot water and will close down the hot inlet port, deadheading the pump and reducing system flow.

What are two common hydronic piping systems?

• One-Pipe Main – With this system, each terminal unit is connected by a supply and a return branch pipe to the main. …
• Two-Pipe Direct Return – This is generally used for larger systems and consists of two mains.

What causes a mixing valve to fail?

Inconsistent Hot Water Older model hot water mixing valves age over time and can break down with usage. As a result they can begin to fail in correctly controlling water temperature.

Does a venturi cool air?

The venturi effect by itself will not heat or cool a room. It is just a low pressure region due to the higher velocity fluid stream created by a restriction in the pipe the fluid is flowing in.

Does temperature drop in a venturi?

Abstract. The expansion of the gas through a critical flow Venturi nozzle (CFVN) leads to a 50 °C temperature drop of the gas at the nozzle throat. The body of CFVN is also cooled, which produces several effects on the flow characteristics called thermal effects.

Is the Venturi theory correct?

This theory deals with only the pressure and velocity along the upper surface of the airfoil. It neglects the shape of the lower surface. … The problem with the “Venturi” theory is that it attempts to provide us with the velocity based on an incorrect assumption (the constriction of the flow produces the velocity field).

What is venturi valve?

The venturi valve is a tube with a constricted neck, resulting in an hourglass-like shape. A cone inside the valve is able to move back and forth parallel to the valve’s body (and parallel to the air stream).

How does a venturi measure flow?

A venturi works by measuring the difference in pressure at two different locations. The pressure difference is created by reducing the diameter of the pipe causing the fluid to flow faster. The fast moving fluid has a lower pressure than the slower fluid in the larger section of the venturi.

Is a Venturi a pump?

A Venturi vacuum is created by a pump with compressed air running through it, yet the pump has no moving parts. Compressed air runs through the initial chamber, then a smaller portal that opens into another larger chamber, which is like the first one.

How many PSI is full vacuum?

Vacuum pressure is measured relative to ambient atmospheric pressure. It is referred to as pounds per square inch (vacuum) or PSIV. The electrical output of a vacuum pressure transducer is 0 VDC at 0 PSIV (14.7 PSIA) and full scale output (typically 5 VDC) at full scale vacuum, 14.7 (0 PSIA).

How efficient is a Venturi pump?

The venturi uses 0.9 hp for every three seconds of a 15-second cycle. Therefore, the venturi uses on average 0.18 hp of compressed air over the same cycle period. Consequently, the venturi is “more efficient” in overall running costs. … The pump and the venturi are always operating to hold the plastic sheet in place.

What is hot tapping in oil and gas?

Hot tapping, also known as pressure tapping, is a method of connecting (either by drilling or cutting) to a pressurised system, such as a pipeline or pressure vessel, without removing the pipe or tank from service. … Hot tapping strictly refers to the installation of connections to pipelines while they remain in service.
