Trailer wiring generally uses 16 gauge wire, part # 16-1-1. However, with a long trailer like yours you may want to go with a larger like 14 gauge # DW07550-1 or even 12 gauge # 12-1-1. Each size is sold by the foot.

Can I use 18 gauge wire for trailer lights?

With the small load on a trailer, without 12V power or electric brake wiring, I would expect 18 gauge would work. I would not use it for power or brakes, just lighting. If you have LED lighting, or convert your trailer to LEDs, so much the better.

What Gauge is trailer ground wire?

Typically, for a 7 way trailer wire connector, experts recommend a 12-gauge wire for the Red or Black (power) wire, the White (ground) wire, and the Blue (brake power).

What is the standard trailer wiring?

Trailer Wiring Has 5-Wires White, Yellow, Green, Yellow/Brown, and Green/Brown On a 4-Way flat trailer wiring harness, white is the ground, brown is running lights, yellow is left turn signal and green is right turn signal. It sounds like your trailer has a wishbone harness.

What gauge wire is a 4 pin trailer plug?

Its 4-pin plug means this harness can connect to most standard trailer wires. Its 16 gauge wire is perfect for attaching to brake lights, turn signals, and tail lights.

What is a 18 gauge wire?

An 18 awg solid bare copper wire is the most basic because it doesn’t even have insulation at all. It’s a solid piece of copper used as a ground wire for most electrical applications. … It’s manufactured with a PTFE insulation and silver plated copper strands rating it as high as 200°C.

How many amps will 16 gauge wire carry?

Types of CordGauge Size RangeAmpacity of Current-Carrying Conductors (amperes)0 – 50 ft. (0 – 15.2 m)SOOW – Service Oil Resistant Insulation/ Jacket Weather-resistant16 AWG13 Amps 10 Amps14 AWG18 Amps 15 Amps12 AWG25 Amps 20 Amps

What is green wire on trailer lights?

The green wire on the right side carries right turn signal and brake light functions, while the brown wire carries running light functions. On the left side, the yellow wire carries the left turn and brake lights and the brown wire carries the running lights.

What is the white wire on trailer lights?

The White Wire is the “Ground” or “Negative” wire connecting to the vehicle battery “minus” side. The trailer wiring diagram shows this wire going to all the lights and brakes. Also, it must connect with things (if included) that use the Aux Power and Back-up lights too.

What is red wire on trailer lights?

The red wire is the turn signal wire and will be run to the green wire of your harness if its the right turn signal side, and the black wire will run to the brown wire of your harness. The yellow wire from your harness will run to the left turn signal red wire.

Article first time published on

What is the blue wire for on a 7 pin trailer plug?

It is an auxiliary wire typically used to connect the reverse lights from the tow vehicle to the reverse lockout solenoid located directly behind a surge brake actuator. When properly connected it allows you to disengage the trailer brakes in order to back the trailer up (without getting out of the vehicle).

How many amps will 14 gauge wire carry?

According to the “powers-that-be”, a 14 gauge wire can carry 20 Amps, but only as a built-in safety measure.

What size cable do I need for 12v LED lights?

Most people would likely recommend using a solid core 18-gauge wire for your LED lights. The cost difference between this wire size and a much smaller cable is negligible, and 18-gauge is about as big as you can go if you would like your wires to fit into most holders or terminals.

What is a 16 gauge wire used for?

16-gauge are used for light-duty extension cords supporting 13 amps. 14-gauge are usedfor light fixtures, lamps, lighting circuits with 15 amps. 12-gauge are used in kitchen, bathroom, outdoor receptacles, and 120-volt air conditioners supporting 20 amps.

What can 16 gauge wire handle?

Wire UseRated AmpacityWire GaugeLow-voltage lighting and lamp cords10 amps18-gaugeExtension cords (light-duty)13 amps16-gaugeLight fixtures, lamps, lighting circuits15 amps14-gaugeKitchen, bathroom, and outdoor receptacles (outlets); 120-volt air conditioners20 amps12-gauge

Can I use 14 gauge wire for lights?

As long as you don’t put too many lights on the light circuit, you can usually control that circuit with a 15-amp breaker, as well as wire it with a 14-gauge wire. … On the other hand, an outlet circuit controlled by a 20-amp breaker requires a 12-gauge wire.

How do I know if my wire is 12 or 14 gauge?

Here’s a simple visual. Twelve gauge is about the thickness of a nickel, and 14-gauge is about the thickness of a dime. Also, look at the breaker for the circuit in question to see if it’s a 15-amp or a 20-amp breaker. A 20-amp circuit requires wire that’s 12-gauge or larger.

How do I know what gauge wire to use?

To determine what gauge wire you need, consider the carrying capacity and the amount of current the wire needs to conduct (measured in amperage or amps). Wire gauge is directly related to how many amps you need to run through it. The distance you need the wire to go can also impact the gauge of wire you need.

Do trailer lights need to be grounded?

Each lamp needs to be grounded either through its mounting studs being in direct contact with the trailer frame or by having a jumper wire ran from the lamp to the trailer frame. Ground the trailer connector at the front of the trailer, which will use the trailer frame as a ground wire.

Are all 7 pin trailer connectors wired the same?

Helpful Expert Reply: Yes, there is only one type of 7-way blade connector.

What are the red white and black wires on trailer lights?

It is likely that the red wire on your old lights is the turn signal/brake light wire and the black wire is the running light wire. That would make the white wire the ground. You can verify this by testing the wires using a circuit tester such as # 40376.

Why are my trailer lights not working?

Because the most common reason for trailer lights not working properly is a bad or missing ground, check the trailer’s and truck’s ground connection first. A poor ground often becomes the culprit when only some lighting functions are working and when lights go out when you push the brake pedal.

Which wire is hot on trailer wiring?

The only wires that could be hot all the time on a trailer connector are the 12 volt hot lead, which is usually a black wire, and, if applicable, the auxiliary power wire, which is normally yellow or purple. The blue wire is usually for electric trailer brakes and if it is hot all the time that would indicate a short.

What are the colors for trailer wires?

• Brown wire to the tail or parking lights.
• Green wire to right turn signal/brake light.
• Yellow wire to the left turn signal/brake light.
• White wire to common or chassis ground.

Why is white wire ground on a trailer?

Expert Reply: The white wire is going to be the ground wire. It will attach to a clean and corrosion free bare metal surface. … Normally on a trailer wiring harness the brown wire is running lights, yellow is left turn signal and brake lights, and green is right turn signal and brake lights.

What is the black wire on trailer lights?

The black wire of the Hopkins 7-Way Molded Trailer Wire Connector # HM20048 carries the 12 volt accessory circuit. This is the circuit that will typically power interior lights or charge a trailer’s battery.

What is the yellow wire for on a trailer?

On the left side, the yellow wire carries left turn and brake lights and the brown wire again carries the running lights. With only 2 wires, these lights must ground through the mounting studs. Make sure to wire in the new lights by function to the existing trailer wiring and not by color.

What color is the ground wire?

According to Mark Dawson, chief operating officer of Mister Sparky, “green insulated wires are used for grounding.” Green is the most common ground wire color, but “green-yellow” (green wire with a yellow stripe) and “bare” wire (copper wire without colored insulation) can also be used.

What are the 3 wires on LED lights?

LED Lights with 3 wires will be a multi-function light. They can (most times) be used in whatever configuration is right for your application. For example, running and brake, running and blinker or brake and blinker. These LED’s will usually have a black, red and white wire.

Where does the red wire go on a trailer?

If you have the right turn signal side, the red wire will run to the green wire of your harness, while the black wire will run to the brown wire. The yellow wire will go to the left turn signal.

What color wire goes to trailer brakes?

The green wire is the right turn/brake, the yellow wire is the left turn/brake, the white wire is the ground, and the brown wire is the electric wire. It is best to wire by function as wire colors can vary.
