2×8 for joists will be fine, with 16″ OC. Should use 2×10 for beams but 2×8 will be fine as well. If you are worried you can triple the 2×8 for the beams but double will be sufficient. You should put the beams at 7 and 14 feet out from the house, with the piers you should do 3 per beam with spacing of 1, 7, 13.

Should deck joist be 2x8 or 2x10?

2×8 for joists will be fine, with 16″ OC. Should use 2×10 for beams but 2×8 will be fine as well. If you are worried you can triple the 2×8 for the beams but double will be sufficient. You should put the beams at 7 and 14 feet out from the house, with the piers you should do 3 per beam with spacing of 1, 7, 13.

What size wood should I use for decking frame?

Commonly used joist sizes are 2-by-6, 2-by-8 and 2-by-10. For example, when you space joists 16″ apart — which is standard for residential decks — a deck spanning 9 1/2′ would require 2-by-6 joists, a 13′ deck would need 2-by-8 joists and a 16′ deck calls for 2-by-10 joists.

Can I use 2x8 for deck beam?

Joists spaced the standard 16 inches apart can span 1.5 times their depth in feet. A 2×6 joist can span up to 9 feet, a 2×8 can span up to 12 feet, and a 2×10 can span up to 15 feet. With this in mind, the depth of the joist determines the spacing of the beams.

How far can a 2x8 span for a deck?

Depending on various factors, the maximum span for a 2×8 floor joist is 16′ 6”. The maximum span for roof rafters is 23′ 9”. For headers, the maximum span is 11′ 2”. Finally, a single deck beam has a maximum span of 5′ 11” and double maxes out at 8′ 9”.

Should deck joists be 2x6 or 2x8?

That’s a model deck code which includes joist span tables. If there is to be a railing, you need the joists to be at least 2x8s. 2x6s don’t have the depth needed to resist the leverage that can be placed on a railing post bolted to them.

How far can a 2x10 span without support?

How Far Can a 2×10 Beam or Header Span? A 2×10 beam – made up of two 2x10s nailed together – can span up to 11′ without support beneath a deck that is 4′ wide. For a more normal-sized deck, the same beam can span 8′, supporting a deck that is 8′ wide. You can also triple a 2×10 beam.

How much weight can a 2x8 hold on edge?

Span (feet)Weight Supported (lb)2 x 2″ x 6″3 x 2″ x 8″61680469083990103190

How far can a 2x8 span without support?

A rule of thumb is 1.5 times a joist’s depth but in feet when spaced at 16” centers. In general, a 2×8 will span 1.5 x 8, so 12-feet.

How far apart should support beams be for a deck?

Deck joists are typically spaced either every 12 inches or 16 inches on center. The maximum joist spacing you can use will depend on the size and allowable span of your joists.

Article first time published on

What size should deck bearers be?

The bearers have to carry the weight of the entire deck and whatever is put on top of it, so they need to be strong. A 140×45 treated pine bearer will usually do the trick. Every 1.2 metres, a 90×90 H4 treated pine post will be needed.

How much gap do you leave between decking boards?

SPACING BETWEEN DECK BOARDS Ensure there is a minimum gap of 5-6mm between each deck board.

How do you stagger deck boards?

A common method for staggering a deck is to start the first row with a full plank, then cut one-third of the next row’s first board off the end. The row after that has an additional one-third cut off and then repeat when you get back to a full board.

Should I use deck boards or 2x6?

2×6 is thicker and is stronger, but is also more expensive. Spacing between deck boards provide a few critical functions. The primary function is to drain water from the deck. Gaps that are narrow (1/8”), can catch debris, specifically on top of the joists, and can be difficult to clean out.

Do I need joist hangers for decking?

Are Joist Hangers Necessary? No, joist hangers are not necessary.

How much weight can a 2x10 floor support?

Each 2×10 will support 1,200 lbs.

How far can a 2x10 span for deck?

Joist Spacing (o.c.)24″Douglas Fir-Larch, Hem-Fir, Spruce-Pine-Fir2x89′-1″2×1011′-1″2×1212′-10″Redwood, Western Cedars, Ponderosa Pine, Red Pine2x66′-10″

Can I use 2x8 for floor joists?

The rule of thumb is 1″ of depth for each foot of run. EX an 8′ span should have a 2×8 joist. The same rule of thumb applies to door and window headers but you should use 4x wood. Ex an 8 foot window header should have an 8′4×8.

How far can you cantilever a 2x10 deck joist?

Joist Cantilevers According to the new span tables and IRC provisions, cantilevers can extend up to one-fourth the backspan of the joist. This means that joists, such as southern pine 2x10s at 16 inches on-center, spanning 12 feet are allowed to cantilever up to an additional 3 feet (see illustration, below).

How thick should deck boards be?

NOTE: Standard boards are often called a 5/4 board when referring to traditional lumber, which means the actual thickness is typically somewhere between 1” and 1 ¼”. Thicker boards are often called a 2 x 6 when referring to traditional lumber, which means the actual thickness is somewhere between 1.2” and 1.5”.

What do you frame a deck with?

MaterialQuantityUsage2x8 Joist Hangers12Used at each typical joist at the ledger and at the outer rim beam

How much weight can a 2x10 hold horizontally?

Each 2×10 will support 1,200 lbs.

How far can you cantilever a 2x8 deck joist?

The American Wood Council states that cantilevers are limited to 1/4 the span of the joists. Joist Spacing (o.c.) Maximum allowable overhang cannot exceed 1/4 of the actual main span.

Do deck joists need blocking?

According to National Design Specifications (NDS) blocking is required on any deck joist over 8ft long on 2″x 10″ and 2″ x 12″ material. … Blocking is easier to install it while you are building the deck, as opposed to having to go back and install it after the decking boards are installed.

How far can you span a triple 2x10 beam?

How Far Can a Triple 2×10 Beam Span? A triple #2 – 2×10 beam of Southern pine can span between 7′-6” and 13′-0” with a live load of 40PSF depending on the joist span. Using DF-L, Hem-Fir, or SPF and the span changes to 7′-2” and 12’6” under the same conditions.

How much does an 8 foot 2x8 weigh?

The answer is 18 – 35 lbs.

Can I drill a 2 hole in a 2x8 floor joist?

The hole cannot be larger than one-third the depth of the joist, so the maximum hole size for a 2×12 joist (actual size 1-1/2 x 11-1/4 in.) is 3-3/4 in. diameter—plenty big enough for running cable! You can drill the holes anywhere along the length of the joist (first photo).

How many footings do I need for a 12x16 deck?

A standard deck will need four footings parallel to the house, but they will need to be temporarily braced by 6 inch-by-6 inch posts. Using doubled boards, you will then need to build beams on the top row of the posts to frame the edges of the deck. These must be topped with adjustable post caps.

Should deck boards run parallel or perpendicular to house?

Decking running parallel to the house makes the deck look wider and blends the deck into the house. If the decking runs perpendicular, the deck looks long and extending far out, away from the house.

What size beams should I use for a deck?

Deck Beam Lumber SizeHow Long the Beam Can Span2×63 feet2×84 feet2×105 feet2×126 feet

Should you paint deck joists?

Coat the joists with a moisture-resistant stain or sealer before you install them to provide an extra level of protection. Paint all the surfaces and edges with a paintbrush, making sure you provide a generous coating on the ends.
