How wide are composite deck boards? Deck boards from popular composite decking brands such as Trex, DuraLife, and Deckorators usually measure in at 5-1/2 inches wide.

What width do decking boards come in?

Decking widths typically range from 90mm to 150mm, with 120mm and 140mm in between.

Does composite decking come in different widths?

Composite decking size refers to the length and width of the boards used for deck building and repairs. Most manufacturers offer composite decking boards in 12′, 16′ and 20′ lengths. The width varies by brand and style and can range from one to two inches thick and four to six inches wide.

What is the width of a Trex deck board?

The boards are 0.75 inches thick and 11.375 inches wide. The Grooved Edge board is 1 inch thick and 5.5 inches wide. It is available in 12, 16 or 20 foot lengths.

How wide is a 6 inch deck board?

Nominal SizeActual Size5/4 × 61″ × 5-1/2″6/4 × 61-5/16″ × 5-1/2″

What size is composite decking?

The length of composite decking boards comes in 6′, 12′, 16′ and up to 20′. The width of the composite board also varies and can range from 1 to 2 inches thick and 4 to 6 inches wide.

How far apart should Trex boards be spaced?

One of the most critical steps for properly securing composite decking in place is to make sure you have a 1/4-inch to 3/16-inch gap between the decking boards (don’t exceed 1/2 inch).

How wide is TimberTech composite decking?

Featuring a distinct, wirebrushed, low-gloss texture, and six dynamic colors, TimberTech AZEK’s Vintage Collection now comes in three widths: narrow (3 1⁄2”), standard (5 1⁄2”) and wide (7 1⁄4”). The narrow deck boards provide a look reminiscent of coastal Cape Cod while the wide planks allow homeowners to think big.

What is the spacing between Trex deck boards?

All deck boards must always be installed with a 6mm side-to-side gap. The Trex Hideaway Hidden Fasteners automatically measure the 6mm gap between grooved edge boards but you must still ensure the 6mm gap with the square edge boards.

How wide are TimberTech decking boards?

You can now choose wide (7.25″) or narrow (3.5″) widths, in addition to standard (5.5″)-width boards, to add a touch of the unexpected – and an element of style. Follow the wide-width flooring trend making its way outdoors.

Article first time published on

What is the widest decking board?

How wide are deck boards? The most common decking widths are 90mm to 150mm, with 120mm and 140mm in between. The width option you choose for your project can make a big impact in the ultimate effect, so get creative to achieve the best look for your decking while staying within your budget.

What is the actual width of a 5 4 deck board?

Nominal SizeRough SizeActual Size: Surfaced 2 Sides5/4 inch1 1/4 inch1 1/16 inch (27 mm)6/4 inch1 1/2 inch1 5/16 inch (33 mm)8/4 inch2 inches1 3/4 inch (44 mm)12/4 inch3 inches2 3/4 inch (70 mm)

How wide is an 8 inch board?

Nominal SizeActual Size2 x 31 1/2 x 2 1/2 inches (38 x 64 mm)2 x 41 1/2 x 3 1/2 inches (38 x 89 mm)2 x 61 1/2 x 5 1/2 inches (38 x 140 mm)2 x 81 1/2 x 7 1/4 inches (38 x 184 mm)

How wide is 5 4 decking?

5/4 Decking Actual Dimensions 1″ x 5.5.”

How many Trex boards do I need for a 12x12 deck?

Board lengthBoards required8 FT20612 FT13716 FT10320 FT83

Do composite deck boards need a gap?

As temperatures fluctuate, composite deck boards will naturally experience thermal expansion and contraction. That’s why the board ends should never be installed tight against one another. There should always be a slight gap.

Can Trex be installed on 16 inch centers?

Most composite and PVC decking brands, like Trex and Azek, recommend a maximum joist spacing of 16 inches OC. Some brands, like WearDeck, let you get away with more – reinforced with a layer of fiberglass on both the top and bottom, WearDeck boards easily allow for spans of 24 inches OC.

What thickness is composite decking?

Length: 4800mm, Width: 138mm, Thickness: 23mm. UltraShield Grey Composite Decking Boards. UltraShield Composite Decking can be installed for commercial and residential applications.

How thick is composite decking?

In summary, a square hollow core decking board of any thickness for residential/home decking projects must be a minimum of 5mm in depth on the side and top walls to ensure the required strength over the decks service life.

How thick is a standard deck board?

NOTE: Standard boards are often called a 5/4 board when referring to traditional lumber, which means the actual thickness is typically somewhere between 1” and 1 ¼”. Thicker boards are often called a 2 x 6 when referring to traditional lumber, which means the actual thickness is somewhere between 1.2” and 1.5”.

How wide should joists be on a deck?

Commonly used joist sizes are 2-by-6, 2-by-8 and 2-by-10. For example, when you space joists 16″ apart — which is standard for residential decks — a deck spanning 9 1/2′ would require 2-by-6 joists, a 13′ deck would need 2-by-8 joists and a 16′ deck calls for 2-by-10 joists.

Can you install Trex with no gaps?

When installing in temperatures below 4.5°C, Trex recommends 10 mm gapping. For docks and heavily wooded areas, Trex recommends a 10 mm gap as well. No gapping should ever exceed 13 mm.

What is a 5 4 deck board?

The most popular thickness for decking boards in North America is a 5/4 thickness which is an actual 1” thick. Use the table below to understand the most common board thicknesses: Decking Thickness Definition Table. Nominal Thickness.

What is the difference between Trex and AZEK?

The main difference between Azek and Trex decking is the material component for each. While Azek decking is entirely made from PVC, Trex is made from a composite of recycled wood chips and recycled plastic compressed together and considered as a capped composite decking.

Are azek and TimberTech the same company?

Traditionally, the company went to market under both the AZEK and TimberTech brand names. TimberTech will now be the umbrella brand for all decking, railing, porch, paver, fastening and lighting products. The trim and moulding business will be positioned under the newly branded AZEK® Exteriors.

Can you use 1x6 for decking?

Never use 1×6 or 5/4×6 material in close to ground applications. Spacing between boards: You must allow space for your deck boards to expand when they take on moisture, as they will inevitably do when exposed to wet weather, rain or high humidity.

What is a 5 4 inch board?

5/4 lumber is lumber that was rough sawn to 1 1/4 inch. When it is finished planed as you would get at a retail lumberyard, it will measure about 1″ though that can sometiimes vary upward.

How much does it cost to space deck boards?

Proper wood deck board spacing should have at least a 1/8 inch gap after the decking has dried out. If you install your wood or treated deck boards while they are still wet boards, then they should be attached without a gap between them.

Are wider deck boards better?

Narrower boards work best. 4” nominal (3-1/2” actual) wide deck boards perform better than wider (6” nominal) deck boards. Because there are more gaps between the deck boards, 4” nominal deck boards provide about 44% more top of deck ventilation than 6” nominal decking.

How wide should a deck be?

A good size deck starts at 12 feet by 12 feet but can be as small as 8 feet by 8 feet for limited specialty use, such as a sitting area or a barbeque area just outside of the kitchen. Also deck should be no larger than the largest room in the house and not exceed 20% of the house square footage.

Why do they call it 5 4 decking?

It simply refers to how many 1/4-inches thick the rough stock is. For example, 4/4 (read out loud as four-quarters) is 1-in. thick in the rough. 5/4 is 1-1/4-in.
