Dry pipe sprinkler systems are filled with pressurized air or nitrogen instead of water to prevent frozen and burst sprinkler pipes in areas with colder temperatures. The pressurized air in the sprinkler pipes prevents water from entering the pipes.

How is a dry sprinkler system activated?

A dry sprinkler system is much like a wet sprinkler system, but inside the pipes is pressurized air instead of water that can freeze. … Heat from the fire activates a sprinkler head, and water, now spraying from the activated head, suppresses the growth of the fire.

How does a dry pendent sprinkler head work?

Dry pendent sprinklers are intended to extend into an unheated area from a wet pipe system such as in a freezer. The sprinklers are fed from a drop where the drop is free of water. A seal is provided at the entrance of the dry sprinkler to prevent water from entering until the sprinkler head activates.

What's the difference between a wet and dry sprinkler system?

Wet vs. Dry Pipe Sprinkler Systems In a wet system, the pipes are filled with pressurized water. When a fire occurs, the system immediately discharges water to extinguish the fire. Conversely, dry systems are filled with pressurized nitrogen or air that keeps water at a riser.

When would you use a dry sprinkler system?

Dry pipe sprinkler systems are ideal for environments where temperatures drop below 40⁰ F since the pipes do not hold water. These fire safety systems are usually installed in buildings that store sensitive equipment because it can help reduce potential damage to the property.

At what temperature do sprinkler heads activate?

What DOES Set Off Fire Sprinklers? Fire sprinkler systems are actually quite sophisticated, and are designed to be heat sensitive so that sprinklers only activate when the temperatures rise to fire-induced temps, usually somewhere between 155 to 165 degrees Fahrenheit.

Does every sprinkler go off in a fire?

“When a fire occurs, every sprinkler head goes off.” Fact: Sprinkler heads are individually activated by fire temperatures in excess of 155°. Residential fires are usually controlled with one sprinkler head.

How do I know if my OS&Y valve is open?

An OS&Y valve is open when the threaded stem extends from the valve. The valve is closed when the stem is not visible above the control wheel.

What activates a wet sprinkler system?

A wet fire sprinkler system means that, at all times, the overhead fire sprinkler piping is filled with pressurized water. When a fire occurs and the heat activates the sprinklers, water immediately sprays from the activated sprinkler heads.

What is a dry barrel sprinkler?

The core challenge of developing and listing a dry sprinkler is its ability to manage cold conduction as temperatures move from a freezing space to the water seal in the barrel. To achieve this, the dry barrel inlet is comprised of an inlet seal, plug, yoke, and spring.

Article first time published on

How does a dry pipe valve work?

Located in a heated space, the dry-pipe valve prevents water from entering the pipe until a fire causes one or more sprinklers to operate. Once this happens, the air escapes and the dry pipe valve releases. Water then enters the pipe, flowing through open sprinklers onto the fire.

Can you convert a dry sprinkler system to wet?

First off, it is more difficult to convert a wet system to a dry system than it is to convert a dry system into a wet due to the codes regulating dry systems. For instance, dry systems require a greater pitch to the pipe to allow any water or condensation to drain, so pipe pitch would have to be adjusted.

Can a dry sprinkler system freeze?

“Dry pipe” fire sprinklers are typically found in unheated attic spaces or warehouses in cold climates. … Now the pipe is “wet,” and in an unheated space, it can freeze and burst, potentially causing significant property damage and business interruption.

What is the difference between a dry system and a pre-action system?

Pre-action fire sprinkler systems employ the basic concept of a dry pipe system in that water is not normally contained within the pipes. The difference, however, is that water is held from piping by an electrically operated valve, known as a pre-action valve.

What does dry pipe mean?

noun. : a sprinkler system in which water is admitted to the system upon the release of air pressure that the pipes normally contain and which is used where there is danger of freezing.

What is the difference between deluge and sprinkler system?

The main difference between a deluge sprinkler system and any other sprinkler system is the sprinklers themselves. … A deluge system, however, has open sprinkler heads at all times. The pipes, instead of being filled with water, or pressurized air, are full of air at the surrounding atmospheric pressure.

Can a candle set off a sprinkler?

While there’s a small chance of setting off your fire alarm while smoking, vaping, cooking, or burning candles or incense, rest assured that these items won’t set off the fire sprinklers. The only exception to this statement is if you hold a lighter or candle flame directly up to a sprinkler head.

Are sprinklers activated by smoke or heat?

Sprinklers are highly reliable devices that are activated by heat. They will only go off if there is a fire which increases the heat beyond the sprinkler trigger point (typically 135 to 165°F (57.2 to 73.9°C)).

Why is fire sprinkler water black?

By far the most common corrosion reaction found in fire sprinkler systems is oxidation. Oxygen trapped inside the system dissolves into water and reacts with the internal surface of the black or galvanized steel piping.

Do sprinkler heads detect smoke?

Rest assured that while there’s a small possibility of triggering a fire alarm by smoking or vaping, there’s no chance of setting off the fire sprinklers. Contrary to popular belief, sprinkler heads are triggered by heat, not smoke or vapor. … This means fire sprinklers are heat detectors rather than smoke detectors.

What liquid is in a sprinkler head?

When a sprinkler head has a glass bulb, that bulb typically contains a glycerin-based liquid. Once the air around the sprinkler reaches a certain temperature – often 155F or 200F (68C or 93C) – the liquid expands which causes the glass to break.

Can steam set off a sprinkler system?

While we’re at it, let’s clear up another myth: despite popular belief, smoke, cooking vapors, or a little steam won’t trigger a fire sprinkler. There’s no reason to worry that you will cause a flood if you install fire sprinklers and burn your toast.

How many sprinklers are triggered at once?

Fire sprinkler systems are actually heat activated, one sprinkler head at a time, and most fires usually require only one or two sprinklers to be extinguished. These are just two of the many misconceptions about fire sprinkler systems.

What does OS&Y valve stand for?

One type of valve commonly used to control water flow to fire sprinkler systems is known as an OS&Y gate valve. OS&Y means “outside stem and yoke” or “outside screw and yoke”.

Which way closes a gate valve?

Gate valves close by turning the wheel clockwise until the water is off. Ball valves close by turning the straight handle a quarter turn clockwise until the water is off.

What is a globe valve?

A globe valve regulates flow in a pipeline. It is used to control or stop the flow of liquid or gas through a pipe. Globe valves are named for their spherical body shape with the two halves of the body being separated by an internal baffle. … Globe valves are also known as throttle valves.

How often do sprinkler heads need to be tested?

Every 10 Years. Dry sprinkler systems should be tested and/or replaced after ten years. Fast-response sprinklers should be tested after 20 years and at 10-year intervals after that, and standard sprinklers should be tested after 50 years and then at subsequent 10-year intervals.

Which type of sprinkler head could be oriented to discharge water up and down with 40 to 60 percent of the water initially flowing downward upon activation?

CONVENTIONAL SPRINKLER: An “old style” sprinkler intended to be installed with the deflector in either the upright or pendent position. The deflector provides a spherical type pattern with 40 to 60 percent of the water initially directed downward and a proportion directed upward.

How do you test for dry system?

Open a valve on the system to release the air or nitrogen. Watch the system air or nitrogen gauge and document the pressure at which the dry valve trips. Immediately close tightly the system control valve and fully open the main drain valve.

What are the components of a dry pipe sprinkler system?

• The valve is in the closed position (clapper inside the valve is horizontal) and air pressure keeps the clapper closed.
• A sprinkler activates, releasing air pressure at the sprinkler.
• Air pressure within the dry pipe system begins to reduce.

What causes a wet pipe sprinkler to activate?

When the air around a sprinkler reaches a certain temperature, the liquid inside the bulb expands until the pressure causes the glass to break. In wet sprinkler systems, pressurized water in the pipes then forces out the plug and flows over a deflector plate that sprays it onto the fire in a carefully designed pattern.
