NOTE: Mounting the TXV in the upright position is preferred. Mounting TXV upside down may increase the chance that debris could deposit on the internal check valve and hold the check valve open during cooling and act as a bleed port.

Can you mount a TXV valve upside down?

NOTE: Mounting the TXV in the upright position is preferred. Mounting TXV upside down may increase the chance that debris could deposit on the internal check valve and hold the check valve open during cooling and act as a bleed port.

Is TXV directional?

Another system consists of one common TXV with bi-directional flow, as in Figure 5. … This means lower cost to the OEM’s so these systems are quite popular. Note that the bulb of the bi-flow TXV is located on the suction line between the reversing valve and the compressor.

Does a TXV need to be upright?

The bulb should never be placed at 6 o’clock. Always insulate the entire sensing bulb after installation. A sensing bulb can be installed on a vertical suction line if necessary, but never place the bulb downstream of a trap.

How should a TXV be mounted?

1. Mount the bulb on the suction line. …
2. Mount it TIGHTLY with a proper metallic strap (usually copper, brass, or stainless steel)—not with zip ties or tape.
3. Position it on a flat, clean, smooth portion of the horizontal suction line—not on a coupling or an elbow.

Can you put a TXV bulb vertical?

If necessary, the bulb can be installed on a vertical suction line. In this instance, the bulb must be placed before any trap, with the bulb’s capillary tube facing upward.

When should an externally equalized TXV be used?

An externally equalized TXV is required whenever the pressure drop in the evaporator exceeds 3 psig (a/c applications); 2 psig (commercial refrigeration applications); or 1 psig (low-temp applications).

What is a bidirectional TXV?

The “Bi-Directional” Thermostatic Expansion Valve has successfully been used to replace two expansion devices as shown in Figure 2. It controls refrigerant flow to either coil when the coil is serving as the system evaporator. … This flow direction will normally result in a lower superheat in the heating mode.

What are the 3 pressures controlling the expansion valve?

There are three different forces at work in a TXV: bulb pressure, spring pressure, and evaporator pressure (see Figure 4).

Why is automatic expansion valve not used?

When the load on the evaporator is high it won’t allow more flow of the refrigerant as per the requirement. … Thus the automatic expansion valve does not allow the control of the flow of the refrigerant through it which is very important for the efficient operation of the refrigeration plant.

Article first time published on

Does a TXV fail open or closed?

Q: How do they fail? A: A TXV may fail either too far open or too far closed. … If the TXV fails closed, it can be said to be “underfeeding,” which means that not enough boiling refrigerant is fed through the evaporator coil; superheat will be too high at the evaporator outlet.

What causes a TXV to overfeed?

A TXV can overfeed from restricted air flow, return air blocked, dirty evaporator coil, dirty air filter, or a bad indoor fan. As you can see, there are many outside factors that can cause a TXV to have exhibit problems other than the TXV itself. While it can be done, it is difficult to check a TXV.

What force is Cancelled out when using a balanced port TXV?

There is also a liquid force from the liquid line, which acts on the face of the needle valve and has a tendency to open the valve. However, this force is cancelled out when using a balanced port TXV. Working together, these forces maintain a constant evaporator superheat in a refrigeration system.

Where should TXV bulb be mounted?

The sensing bulb needs to be mounted on a horizontal section of the suction line in the 3-o’clock or 9-clock position. Insulate the sensing bulb thoroughly so that it receives a good temperature signal from the gas in the sensing bulb.

Can an internally equalized TXV be replaced with an externally equalized TXV?

An internally equalized TXV uses evaporator inlet pressure to create the ‘closing’ force on the valve. … Note: For field replacement you can always replace an internally equalized valve with an externally equalized type; however, you should never replace an externally equalized valve with an internal type.

What type of evaporator will need an externally equalized valve?

An externally equalized valve should be used on any evaporator with a multiple refrigerant circuits and a distributor because the typical refrigerant distributor and distributor tubes will have approximately a 35 psi pressure drop.

Why are externally equalized valves needed on some evaporators?

Why are externally equalized valves needed on some evaporators? Because of the high pressure drop in the distributors. … The capacity decreases because of less pressure drop across the valve. What happens to the capacity of a TEV as the liquid temperature decreases?

Is the suction line the liquid line?

Refrigerant Lines The larger line typically carries a cool gas and is insulated. This is commonly referred to as the suction line, but it is also called the return line or vapor line. The smaller uninsulated line typically carries a warm liquid. It is most often called the liquid line.

What is not a pressure or force acting on a TXV diaphragm?

Therefore, Evaporator pressure, Bulb pressure, and Spring pressure are the active forces which work to move the needle in a TXV diaphragm. Conclusion: The pressure or force that does not act on a TXV diaphragm is Head Pressure.

What causes a TXV to hunt?

Superheat hunting is the result of the expansion valve (see TEV illustration below) excessively opening and closing in an attempt to maintain a constant operating condition. Hunting can be observed as regular fluctuations in suction temperature, and in extremes, suction pressure.

What are the symptoms of a bad TXV?

• Low evaporator (suction) pressure;
• High evaporator and compressor superheats;
• Low compressor amp draw;
• Short-cycling on the low-pressure control;
• Somewhat high discharge temperature;
• Low condensing (head) pressure;
• Low condenser split; and.

What are the signs of a bad expansion valve?

• Car AC system isn’t cooling enough or won’t cool at all. …
• High side pressure is high. …
• Air coming from vents is frosty. …
• AC blows cold, then hot. …
• AC kicks on and then immediately kicks off. …
• Airflow drops dramatically from vents.

What happens if expansion valve goes bad?

You will notice when the A/C expansion valve goes bad because your air conditioning system will ultimately stop functioning properly. It will either produce less cool air or it won’t produce any cool air at all. At this point, you will need to replace your A/C expansion valve to fix the problem.

Does my heat pump have a Txv?

In heat pumps, this TEV or TXV is usually found near the heating coil. Here it has the main task of keeping the right amount of refrigerant going in and out the coil for proper temperature.

Do heat pumps have expansion valves?

The expansion valve most commonly used in the heat pumps is copper capillary tube. The refrigerant leaves the expansion valve at extremely low pressure and low temperature in partially liquid state and partially gaseous state.

How many Btus is a ton?

There’s a complicated mathematical formula involved in converting the weight of that ice into energy, but in the end a “ton” of air conditioning capacity represents roughly 12,000 BTU per hour. So a 2-ton unit has 24,000 BTU/hr capacity and a 3-ton has 36,000 BTU/hr, and so on.

What is the difference between the TXV and AXV valves?

An easy way to tell the difference is to look at the top of the valve. If it has an adjustable screw on top of the diaphragm, it’s an AXV. If it has a capillary tube and sensing bulb connected to the top of the diaphragm, it’s a TXV.

What is an ax valve?

Co-Ax is a highly versatile coaxially-designed process valve that can operate with almost all gaseous, liquid, gelatinous, contaminated, pasty, highly viscous or aggressive media, including vacuum. Its unique design means greater durability, repeatability, precision and performance.

Will a bad TXV cause high head pressure?

TXV (or in some texts TEV) – Thermostatic Expansion Valve – improperly set, iced, contaminated, or clogged or crimpled capillary tube, or having lost power to a TXV power head can cause high pressure and can also cause valve damage by flooding the compressor if instead the valve sticks wide open.

What does high superheat and high subcooling mean?

While superheat indicates how much refrigerant is in the evaporator (high superheat indicates not enough, low superheat indicates too much), subcooling gives an indication of how much refrigerant is in the condenser. … Higher subcooling indicates excess refrigerant backing up in the condenser.

Can you bypass a TXV valve?

You must install a check valve to bypass the TXV when reverse flow is encountered.
