My personal preference for small-shop compressed-air piping is PEX. It’s lightweight and flexible, and the fittings literally snap together. … Because of its flexibility, you can often place PEX where it would be difficult to install rigid pipe, such as in finished walls and ceilings.

Can PEX handle air pressure?

PEX-a pipe can withstand a burst pressure of around 800 psi (almost two times the requirement for ASTM F876, the standard specification for PEX tubing).

Can I use SharkBite for compressed air?

SharkBite, part of RWC’s family of brands, now offers a new range of brass push-fit fittings and anodised aluminium pipe to simplify small to large commercial and industrial compressed air installations. … The range also includes a 45° elbow for better air flow and reduced pressure drops in the airline.

What PSI is PEX piping rated for?

PEX tubing comes in nominal sizes ranging from 1/4 to 3 in. copper tube size (CTS), and pipe sizes in both inch and metric sizes. PEX tubing is SDR9 with standard hydrostatic pressure ratings of 160 psi at 73°F (1105 kPa at 23°C) and 100 psi at 180°F (690 kPa at 82°C).

Can I use PVC pipe for air compressor lines?

PVC Pipe. The use of PVC pipe is common but not recommended for use with compressed air. … However, as with many plastics, PVC gets brittle over time and can crack, break, or even shatter. The presence of air compressor oils in the line and heat from the compressed air accelerates the degradation of PVC.

What kind of pipe is best for compressed air?

A great choice for compressed air piping is stainless steel because it is strong and resists corrosion. Like with copper, corrosion resistance in stainless steel piping produces a cleaner, more consistent stream of air.

What size air line do I need?

Recommended Pipe Size (inches)Free Air Flow (cfm)Length of Pipe (feet)251/21301/21353/41

Can oxygen barrier PEX be used for plumbing?

Oxygen barrier PEX is made for heating applications and has thus not been approved for plumbing and drinking water.

Why is PEX plumbing bad?

Potential chemical leaching is another downside of PEX piping. Due to its chemical composition, the PEX pipe material may leach toxic chemicals including bisphenol (BPA), MTBE, tertiary butyl alcohol (TBA), and others.

Can CPVC pipe be used for compressed air?

No, PVC and CPVC pipe should not be used for compressed air lines. Here is what the manufacture has to say about it. WARNING! The use of plastic piping with compressed air or gasses can result in severe bodily injury or death.

Article first time published on

Can type M copper pipe be used for compressed air?

Copper pipe is a common selection for sensitive compressed air systems and when correctly sized and connected is very durable and effective. Type M hard, type L hard and type K soft copper has a working pressure of 250 psig (17 bar).

What is the life expectancy of a SharkBite fitting?

How long do SharkBite fittings last? SharkBite fittings last a long time. In fact, SharkBite warrants the fittings for 25 years when used with SharkBite tubing.

What PSI can schedule 40 PVC handle?

Trade SizePart NumberPressure Rating (psi)1/25405010P6003/45407510P48015410010P4501-1/45412510P370

How many PSI will PVC hold?

Age And Temperature Of course, PVC doesn’t just shatter or explode out of nowhere. Most consumer air compressors only compress to around 125-175 psi. This doesn’t seem like a whole lot, especially when even the smallest size PVC pipe can generally handle anywhere between 300-600 psi.

What size pipe do I need for compressed air lines?

Typically, you can multiply the capacity of straight-line piping by 1.5 for loop type compressed air distribution systems. For example: If a 2” aluminum pipe is rated for 500 CFM at 125 PSI, that same length of pipe in a loop system would be rated for 750 CFM at 125 PSI.

How far can you run an air compressor line?

Typically, air hoses will be either 50- or 100-feet long, with a few exceptions. Most people will go for the 100-foot option because it allows them to maximize their distance from the air compressor.

Does size of pipe affect air pressure?

Pipe Length: The longer airflow travels, the more significant the pressure drop will be. Make sure you check your compressed air needs and optimize your piping system before installing any new compressed air products. 2. … More often than not, the diameter of your pipe is the most significant restriction to airflow.

Can mice chew through PEX pipe?

Mice and rats will chew through anything they can, including plastic, so PEX tubing is at just as much risk as the plastic-coated wiring in a car or an HVAC unit. While all rodent damage can be expensive, if rodents chew through a home’s PEX water pipes, the result can be disastrous.

Is PEX safe for drinking water 2021?

With a plumbing-pipe offering in sizes up to 3 inches, PEX is challenging traditional copper and CPVC materials for domestic water applications. … This provides confirmation the pipe does not leach harmful substances into drinking water and is safe for potable systems in healthcare facilities.

Where is PEX not allowed?

PEX can’t be installed in high heat areas. You can’t install PEX in high heat areas like near recessed lighting. This also means you can’t connect PEX directly to a hot water heater, but you can use a connecting material to do this.

How do you know if PEX tubing has oxygen barrier?

It often has a shiny gloss to it, compared to non barrier. Rub it together and it will squeak. If you heat it with a match or torch carefully you may see that EVOH layer start to de-laminate from the tube.

Why does PEX have an oxygen barrier?

External coating of oxygen barrier PEX tubing effectively prevents diffusion of oxygen molecules into the water through walls of the pipe. This feature prevents corrosion of cast iron components in the system (circulator pumps, air purgers, fill valves, boiler heating elements, etc.)

What is the maximum pressure air can be compressed?

Atmospheric air has 14 PSI of pressure (1 bar) but can be forced up to 6004 PSI (414 bar) of pressure when compressed into a smaller state. Exactly how pressurized compressed air becomes is determined by science.

Can HDPE be used for compressed air?

Polyethylene (PE) piping and high-density polyethylene (HDPE) piping are also good choices for compressed air applications. PVC is not recommended and is an OSHA violation if used. It degrades and can burst, causing damage and is very dangerous to employees exposed to it.

What type of copper tubing is used for air conditioning?

Hardened copper tubing is used for water lines, commercial refrigeration and HVAC. This type of tubing is joined using grooved, compression, crimped, or sweat connections. The runs are mostly straight except where it must be bent to go around construction.

What type of copper is used for compressed air?

Compressed Air Use copper tube of Types K, L or M determined by the rated internal working pressures as shown in Tables 14.3a-c, e. Brazed joints are recommended.

Can refrigeration copper be used for gas?

The copper used for water supply and distribution is properly called “Copper Pipe” and it is defined by the “ID” (internal dimension). … They make copper tubing that is specifically listed as approved for gas but most gas codes will also allow you to use TYPE ACR (Air conditioning & Refrigeration) copper.

Why do plumbers hate shark bites?

SharkBites work better than plastic quick-connects on copper pipes because the lead-free brass body is rigid like the pipe and has a higher pressure tolerance. … We don’t recommend using a SharkBite fitting outside because sunlight can dry out the rubber O-ring and cause it to crack or split.

Can you use SharkBite on PEX?

SharkBite brass push-to-connect fittings are compatible with PEX, Copper, CPVC, PE-RT and SDR-9 HDPE pipe. SharkBite fittings come with a PEX stiffener pre-loaded into the fitting for PEX, PE-RT and SDR-9 HDPE. The PEX stiffener does not need to be removed for Copper or CPVC applications.

Do SharkBite fittings meet code?

Fact: SharkBite fittings are approved by the Uniform Plumbing Code and International Plumbing Code for permanent installation. … SharkBite Universal fittings are specifically designed to ensure permanent connection, and aren’t intended to be disconnected and reconnected repeatedly.

How do I get water out of my air compressor lines?

1. Air Filters / Separators. The most basic weapon against water is to filter it out using a simple air filter. …
2. Dry The Air. If you have a quality air compressor and want to fully protect it, a refrigerated air dryer is the only way to go. …
3. Oil It Up. …
4. Open The Drain (A Little)
