Nominal vs. … Lumber sizes are usually given in “nominal” measurements. The nominal measurements are a board’s size before it has been planed smooth (surfaced) on all 4 sides. The actual measurements are the final size.

Why is nominal board size different than actual board size?

The nominal measurement is given to the lumber when it is sawn according to the size it is then. Drying and planing decrease the size making either type of actual measurement different than the nominal size.

Why does the actual size differ from the nominal size?

A nominal size can have several different actual sizes. Actual Size is the true size of your filter. If you were to measure your filter, you are getting the actual size of the filter. If this size is listed on the air filter, typically it’s listed below or beside the nominal size in smaller print.

What is the difference between the true size and nominal size of wood?

The “actual” size of the advertised “2×6” piece of lumber is “1-1/2×5-1/2.” The nominal size refers to the original state of the board before secondary processes have occurred. These processes are kiln drying and/or surfacing of the rough-sawn boards that come from the “green” sawmill.

What is the difference between true size and actual size?

The actual size refers to the exact measurements of your air filter, and the true dimensions when you measure the length, width, and depth (thickness). Actual size typically includes a fraction number within the dimensions – for example: 19 1/2″ x 19 1/2″ x 3/4″.

When did lumber dimensions change from actual to nominal?

Early concepts called for rough lumber to be of full nominal size, often in the dry condition. After World War I, the increasing demand for construction lumber led to the first national size standard in 1924. This was revised in 1926, 1928, 1939, and 1953, while still another revision is proposed for adoption in 1964.

Why is a 2x4 not really 2x4?

DIMENSIONAL LUMBER: In the past, when a timber was called a 2×4 [or “two-by-four”], it actually measured 2 inches by 4 inches. … Because of this extra milling, a 2×4 no longer measures a full 2 inches by four inches. Instead, a 2×4 is really only 1 1/2″ by 3 1/2″. The same is true of pine.

What is the difference between nominal and rough lumber?

Rough sawn lumber has a very rustic appearance, which is a desirable look for some projects. … After it is planed, the piece of lumber no longer has its nominal dimensions, for it has been reduced in size. It is stilled referred to by its nominal size, such as the 2×4, but its actual size is now 1 1/2” by 3 1/2″.

What is the actual size of lumber?

Dimensional Lumber: Nominal Size vs. Actual SizeTwo-by-four or 2 x 41 1/2 inches x 3 1/2 inchesTwo-by-six or 2 x 61 1/2 inches x 5 1/2 inchesTwo-by-eight or 2 x 81 1/2 inches x 7 1/4 inchesTwo-by-ten or 2 x 101 1/2 inches x 9 1/4 inches

What is the actual size of a 2x4 board?

The true measurement of a 2×4 is actually about 1.5×3. 5. When the board is first rough sawn from the log, it is a true 2×4, but the drying process and planning of the board reduce it to the finished 1.5×3. 5 size.

Article first time published on

Why is dimensional lumber not actual size?

The “nominal” cross-section dimensions of a piece of lumber, such as 2 X 4 or 1 X 6, are always somewhat larger than the actual, or dressed, dimensions. The reason is that dressed lumber has been surfaced or planed smooth on four sides (called S4S). The nominal measurement is made before the lumber is surfaced.

Is basic size same as nominal size?

Basic size – The basic size is the size to which allowances and tolerances are added to get the limits of size. 4. Nominal size – The nominal size is a designation used for general identification. Typically this is a fraction when working in inches.

Why are the actual dimensions of framing lumber smaller than the nominal dimensions?

Actual measurements are the actual final size of the lumber after it has been dried and planed. Boards will shrink width-wise versus length-wise because of the direction of the grain. This is because wood is anistrophic, meaning that the wood’s properties will change depending on the grain direction.

What is nominal size?

Measurement. In manufacturing, a nominal size or trade size is a size “in name only” used for identification. The nominal size may not match any dimension of the product, but within the domain of that product the nominal size may correspond to a large number of highly standardized dimensions and tolerances.

What is nominal aggregate size?

Superpave defines nominal maximum aggregate size as “one sieve size larger than the first sieve to retain more than 10 percent of the material” (Roberts et al., 1996). Nominal maximum size. The smallest sieve through which 100 percent of the aggregate sample particles pass.

How do you calculate nominal size?

The nominal thickness of hardwood lumber is based on the quarter scale, 4/4, 5/4, 6/4, 8/4, etc. The rough size can be found by dividing the numerator by the denominator. For example, 8/4 lumber is roughly 2” thick (8 divided by 4 equals 2). But once again, the quarter-scale is the nominal thickness.

Why is lumber smaller than the size it says?

Typically, that rough cut is smaller than the nominal dimensions because modern technology makes it possible to use the logs more efficiently. For example, a “2×4” board historically started out as a green, rough board actually 2 by 4 inches (51 mm × 102 mm).

Why is lumber a half inch short?

Wood is hygroscopic, so it adjusts its internal moisture to match the external moisture of its environment. … Without the rough edges, what went in as a 2-by-4 planks of rough-sawn wood is now a tongue-tripping 1.5-by-3.5, having lost approximately ¼-inch on all sides to the planer and drying processes.

When did they stop making true 2x4?

This pressured further compromise because thinner 2x4s were a way to compete in price with wood alternatives. Size standards, maximum moisture content, and nomenclature were agreed upon only as recently as 1964. The nominal 2×4 thus became the actual 1½ x 3½, imperceptibly, a fraction of an inch at a time.

What do they call a 2x4 in Europe?

First : the actual measure of a 2 x 4 is 1.5 by 3.5. 38 x 89 mm is equivalent to a 2 by 4. Originally Answered: What are pieces of lumber called 2x4s (2″x4″ roughly) called in countries that use the metric system? Here in the UK, the equivalent of 2×4 is 100x47mm.

How thick is a 2x12?

Nominal SizeActual Size2 x 61 1/2 x 5 1/2 inches (38 x 140 mm)2 x 81 1/2 x 7 1/4 inches (38 x 184 mm)2 x 101 1/2 x 9 1/4 inches (38 x 235 mm)2 x 121 1/2 x 11 1/4 inches (38 x 286 mm)

What size lumber is used for decking?

For the deck surface, you can use 2x4s, 2x6s, or 5/4x6s. The 5/4 decking (pronounced “five-quarter”), available in cedar and pressure-treated fir, is 1 inch thick and 5-1/2 inches wide with rounded edges that make for a splinter-free surface. Cedar 1x lumber usually has one rough side and one smooth side.

What is #2 lumber?

2 Lumber. No. 2 lumber is the most common grade for framing. Lumber of this grade contains few defects, but knots are allowed of any quality as long as they are well spaced and do not exceed the size regulations.

Why is it called 5 4 board?

It simply refers to how many 1/4-inches thick the rough stock is. … -thick lumber and 5/4 to 1-in. thick.

What is actual metrology size?

Actual size: The size of a part as may be found by measurement. Maximum limit of size: The greater of the two limits of size. Minimum limit of size: The smaller of the two limits of size.

What is the difference between dimensional lumber and studs?

Light framing lumber is 2-inches to 4-inches thick and 4-inches wide. … Dimensional lumber and studs are 2-inches to 4-inches thick and 2-inches to 4-inches wide. Structural joists and planks are 2-inches to 4-inches thick and 6-inches wide. Beams and stringers are at least 5-inches wide and 2-inches thick.

What is the actual size of a 1x10 board?

1x Board Sizes The larger 1x boards (1×8, 1×10, etc.) lose 3/4 inch in width. That means a 1×10 is actually 3/4 inch in thickness by 9 1/4 inches.

Why do 2x4s have rounded edges?

2×4 have rounded edges as it’s very beneficial to the wood itself and those working with it. They reduce the number of injuries like unwanted splinters during the handling and manufacturing process and also ensure that the lumber stays looking its best all throughout until the customer sees it.

Is there a 3x3 wood?

3 in. T x 3 in. Douglas fir is low maintenance, resistant to decay and insects, and easy to paint and stain. …

Is 2x2 lumber actually 2x2?

Nominal MeasurementActual (inches)Actual (mm)2 x 21-1/2 x 1-1/238 x 382 x 41-1/2 x 3-1/238 x 892 x 61-1/2 x 5-1/238 x 1402 x 81-1/2 x 7-1/438 x 184

Why are 2x4 a half inch smaller?

The simple reason why 2×4 is not 2 inches by 4 inches is that lumber mills trim off rough or warped surfaces of a 2×4 to give it a more polished and finished look. By planning the lumber on all four sides, the original 2×4 is now reduced to 1 ½ inches by 3 1/2 inches.
